Anodized aluminum housing (US 28)
12 or 24 VDC (selectable)
No residual magnetism
Adjustable mounting bracket
MOV surge protection
Complete mounting hardware for typical installations
Detachable face plate
UL and ULC listed
CE listed
RoHS compliant
Holding Force 1,200-lb (545kg) per door
Operating Voltage 12 or 24 VDC ±10%
Current Draw 500mA@12VDC per door (1A total) 250mA@24VDC per door (500mA total)
Operating Temperature 14º~131º F (-10º~55º C)
Certification UL, ULC, CE
Electromagnet Dimensions 21"x1-5/8"x2-5/8" (536x42x67 mm)
RoHS Compliance Yes
Armature Dimensions 7-1/4"x5/8"x2-3/8" (185x16x61 mm)
Weight 21-lb (10kg)
-
Item #:
192797
-
SKU:
SL-E-941DA-1K2Q
