The BN020 license allows you to program additional keys for BMW vehicles with BDC02 (Body Domain Controller 2nd generation), used in F- and G-Series, on the bench.
- No soldering required
- Easy and safe connection - only using clips and plugs!
- Spare key addition via OBD can be done after first completing the procedure on the bench!
Please Note: Once the procedure is done successfully on the bench, adding more keys can be done anytime after that via OBD.
Functionality:
Adding a spare key to any F and G Series based vehicles equipped with the body Domain Controller of the second generation (BDC02)(working key required!)
Supported Models:
Any software version of BDC02 installed in
- M5 (F90)
- 5 Series (G30/G31/G38)
- 4 Series (G80/G81/82)
- 6 Series (G32)
- 7 Series (G11/G12)
- X3/X4, IX3 (F97/F98, G01?G02, G08)
- M8 (F91/F92/F93)
- 8 Series (G14/G15/G16)
Supported ECUs/software versions:
- swfl_00001df4.106_020_030
- swfl_00005fa8.108_020_020
- swfl_00005fa8.109_051_010
- swfl_00005fa8.109_067_010
- swfl_00001df4.100_062_020
- swfl_00005fa8.108_030_010
- swfl_00005fa8.109_062_010
- swfl_00001df4.100_150_050
- swfl_00005fa8.109_049_041
- swfl_00005fa8.109_063_040
- swfl_00001df4.102_050_040
- swfl_00005fa8.109_050_050
- swfl_00005fa8.109_065_010
Supported Years:
Usually, BDC02 is installed in most of the above-mentioned models up to around 2021, but there are certainly some late cars still using this generation.
Required Hardware:
- ABRITES Vehicle Diagnostics Interface (AVDI)
- ABRITES Distribution Box Set (ZN151)
- Protag (ZN003)
- BDC2 Bench connector cable (ZN095) - mandatory for the procedure, available at pre-order
- The procedure is non-invasive. It does not require wire soldering or removal of components from the Body Domain Controller itself, and is the best possible solution for the programming of spare (additional) keys to any BDC02 cars.
AVDI with active Annual Subscription is a MUST!
-
Item #:
268894
-
Product Type
Software
-
SKU:
ABRITES-BN020
